LIFTING BELTS

LIFTING BELTS, SINGLE-LAYERED, MADE OF POLYESTER

The lifting belts are manufactured in accordance with EN 1492-1, are extra narrow, especially strong and colour-coded according to the CEN standard. They incorporate interwoven tonnage stripes and boast 1t WLL per 30mm of belt width. The belts also feature tear-proof, sewn in, individual safety labels and guidelines for use. Polyurethane is used to strengthen the lifting belts.

Details

belt width mm	rated load capacity	colour code acc to cen	no. of tonnage stripes	L1 min. mm	L2 mm	loop form
	direct (wll)	parallel (wll)
30	0,5 t	1,0 t	violet	0,5	900	300	1/1
60	1,0 t	2,0 t	green	1	900	300	1/2
90	1,5 t	3,0 t	yellow	1,5	950	350	1/2
120	2,0 t	4,0 t	grey	2	1.400	500	1/2
150	2,5 t	5,0 t	red	2,5	1.500	550	1/2
180	3,0 t	6,0 t	brown	3	1.700	650	1/2
240	4,0 t	8,0 t	blue	4	2.100	800	1/2
300	5,0 t	10,0 t	orange	5	2.500	1.000	1/2

belt width mm	rated load capacity	colour code acc to cen	no. of tonnage stripes	L1 min. mm	L2 mm	loop form
	direct (wll)	parallel (wll)
30	0,5 t	1,0 t	violet	0,5	900	300	1/1
60	1,0 t	2,0 t	green	1	900	300	1/2
90	1,5 t	3,0 t	yellow	1,5	950	350	1/2
120	2,0 t	4,0 t	grey	2	1.400	500	1/2
150	2,5 t	5,0 t	red	2,5	1.500	550	1/2
180	3,0 t	6,0 t	brown	3	1.700	650	1/2
240	4,0 t	8,0 t	blue	4	2.100	800	1/2
300	5,0 t	10,0 t	orange	5	2.500	1.000	1/2

LIFTING BELTS, DOUBLE-LAYERED, MADE OF POLYESTER

The lifting belts are manufactured in accordance with EN 1492-1, are extra narrow, especially strong and colour-coded according to the CEN standard. They incorporate interwoven tonnage stripes and boast 1t WLL per 30mm of belt width. The belts also feature tear-proof, sewn in, individual safety labels and guidelines for use. Polyurethane is used to strengthen the lifting belts.

Details

belt width mm	rated load capacity	colour code acc to cen	no. of tonnage stripes	L1 min. mm	L2 mm	loop form
	direct wll	parallel wll
30	1,0 t	2,0 t	violet	1	900	300	1/1
60	2,0 t	4,0 t	green	2	900	300	1/2
90	3,0 t	6,0 t	yellow	3	950	350	1/2
120	4,0 t	8,0 t	grey	4	1.400	500	1/2
150	5,0 t	10,0 t	red	5	1.500	550	1/2
180	6,0 t	12,0 t	brown	6	1.700	650	1/2
240	8,0 t	16,0 t	blue	8	2.100	800	1/2
300	10,0 t	20,0 t	orange	10	2.500	1.000	1/2

belt width mm	rated load capacity	colour code acc to cen	no. of tonnage stripes	L1 min. mm	L2 mm	loop form
	direct wll	parallel wll
30	1,0 t	2,0 t	violet	1	900	300	1/1
60	2,0 t	4,0 t	green	2	900	300	1/2
90	3,0 t	6,0 t	yellow	3	950	350	1/2
120	4,0 t	8,0 t	grey	4	1.400	500	1/2
150	5,0 t	10,0 t	red	5	1.500	550	1/2
180	6,0 t	12,0 t	brown	6	1.700	650	1/2
240	8,0 t	16,0 t	blue	8	2.100	800	1/2
300	10,0 t	20,0 t	orange	10	2.500	1.000	1/2

LIFTING BELTS, QUADRUPLE-LAYERED, MADE OF POLYESTER

The lifting belts are manufactured in accordance with EN 1492-1, are UV stabilised and colour-coded. Polyurethane coating, safety labelling and reinforced loops are standard with these belts.

Details

belt width mm	rated load capacity	colour code acc to cen	L1 min. mm	L2 mm	loop form
	direct wll	parallel wll
30	2,0 t	4,0 t	violet	1.500	600	1/1
60	4,0 t	8,0 t	green	1.500	600	1/1
90	6,0 t	12,0 t	yellow	1.700	700	1/1
120	8,0 t	16,0 t	grey	2.600	1.000	1/2
150	10,0 t	20,0 t	red	2.900	1.100	1/2
180	12,0 t	24,0 t	braun	3.300	1.300	1/2
240	16,0 t	32,0 t	blue	3.900	1.600	1/2
300	20,0 t	40,0 t	orange	4.700	2.000	1/2

belt width mm	rated load capacity	colour code acc to cen	L1 min. mm	L2 mm	loop form
	direct wll	parallel wll
30	2,0 t	4,0 t	violet	1.500	600	1/1
60	4,0 t	8,0 t	green	1.500	600	1/1
90	6,0 t	12,0 t	yellow	1.700	700	1/1
120	8,0 t	16,0 t	grey	2.600	1.000	1/2
150	10,0 t	20,0 t	red	2.900	1.100	1/2
180	12,0 t	24,0 t	braun	3.300	1.300	1/2
240	16,0 t	32,0 t	blue	3.900	1.600	1/2
300	20,0 t	40,0 t	orange	4.700	2.000	1/2
