CARABINE HOOKS
The standard versions of carabine hooks are made of rustproof stainless steel (material AISI 316). Surfaces feature a polished finish.
Not suitable for carrying or lifting loads!
| material diameter | length | inner width | diameter | breaking load | weight per 100 pieces |
|---|---|---|---|---|---|
|
a mm |
b mm |
c mm |
d mm |
in kg | in kg |
| 4 | 40 | 5 | 7 | 450 | 0,6 |
| 5 | 50 | 7 | 8 | 570 | 0,8 |
| 6 | 60 | 7 | 9 | 670 | 1,6 |
| 7 | 70 | 9 | 10 | 750 | 2,6 |
| 8 | 80 | 11 | 12 | 870 | 4,4 |
| 10 | 100 | 12 | 15 | 1.150 | 9,3 |
| 11 | 120 | 14 | 18 | 1.250 | 12,5 |
| 12 | 140 | 16 | 20 | 1.280 | 19,5 |
Dimensions and technical data subject to change.
