SHACKLES

DEE SHACKLES WITH SCREW PIN

The dee shackles are made of rustproof stainless steel (material AISI 316) and are equipped with a screw pin. Surfaces feature a polished finish.

Details

breaking load	bow diameter	pin diameter	eye diameter	inner width	inner length	weight per 100 pieces
to	a mm	b mm	c mm	d mm	e mm	in kg
0,06	4	4	8	8	16	1,1
0,10	5	5	10	10	20	1,6
0,15	6	6	12	12	24	2,4
0,3	8	8	16	16	32	5,6
0,4	10	10	20	20	40	13
0,6	12	12	24	24	48	20
1	16	16	32	32	64	48
1,5	19	19	38	38	76	84
2	22	22	44	44	88	127
2,4	24	24	50	50	100	184
3,1	32	32	64	64	128	372

breaking load	bow diameter	pin diameter	eye diameter	inner width	inner length	weight per 100 pieces
to	a mm	b mm	c mm	d mm	e mm	in kg
0,06	4	4	8	8	16	1,1
0,10	5	5	10	10	20	1,6
0,15	6	6	12	12	24	2,4
0,3	8	8	16	16	32	5,6
0,4	10	10	20	20	40	13
0,6	12	12	24	24	48	20
1	16	16	32	32	64	48
1,5	19	19	38	38	76	84
2	22	22	44	44	88	127
2,4	24	24	50	50	100	184
3,1	32	32	64	64	128	372

Dimensions and technical data subject to change.

BOW SHACKLES WITH SCREW PIN

The bow shackles are made of rustproof stainless steel (material AISI 316) and are equipped with a screw pin. Surfaces feature a polished finish.

Details

breaking load	bow diameter	pin diameter	eye diameter	inner width	inner length	bow width	weight per 100 pieces
to	a mm	b mm	c mm	d mm	e mm	f mm	in kg
0,06	4	4	8	8	16	14	1,2
0,10	5	5	10	10	20	17	1,8
0,15	6	6	12	12	24	21	2,8
0,24	8	8	16	16	32	28	6,4
0,4	10	10	20	20	40	34	15
0,58	12	12	24	24	48	42	22
0,98	16	16	32	32	64	56	55
1,5	19	19	38	38	76	66	97
2	22	22	44	44	88	77	146
3	25	25	50	50	100	87	211
3,5	28	28	56	56	112	98	285
4,5	32	32	64	64	128	112	326

breaking load	bow diameter	pin diameter	eye diameter	inner width	inner length	bow width	weight per 100 pieces
to	a mm	b mm	c mm	d mm	e mm	f mm	in kg
0,06	4	4	8	8	16	14	1,2
0,10	5	5	10	10	20	17	1,8
0,15	6	6	12	12	24	21	2,8
0,24	8	8	16	16	32	28	6,4
0,4	10	10	20	20	40	34	15
0,58	12	12	24	24	48	42	22
0,98	16	16	32	32	64	56	55
1,5	19	19	38	38	76	66	97
2	22	22	44	44	88	77	146
3	25	25	50	50	100	87	211
3,5	28	28	56	56	112	98	285
4,5	32	32	64	64	128	112	326

Dimensions and technical data subject to change.

STAINLESS STEEL SHACKLES

The shackles are made of high tensile 1.4542 rustproof stainless steel. Available in dee form as: Type A with collar pin; Type B with pin and slotted bolt; and Type C with long bolt and pin hole, bowed. Also available in bowed form.

Details

Schäkel, geschmiedet und getestet aus hochfestem Edelstahl

STAINLESS STEEL SHACKLES, DEE

d1 mm	d2 mm	d3 mm	bi mm	li mm	brl kg	swl tested
10	8	19	16	32	7.000	1.000
12,7	10	25	20	40	10.000	2.000
16	12,7	32	25	50	15.000	3.000
19	16	37	32	64	25.000	5.000
22,2	19	44	38	76	35.000	7.000
25,4	22,2	51	44	88	45.000	9.000
28,6	25,4	57	51	102	55.000	11.000
31,8	28,6	64	57	114	65.000	13.000
34,9	31,8	70	64	128	75.000	15.000
38	34,9	76	70	140	90.000	18.000

d1 mm	d2 mm	d3 mm	bi mm	li mm	brl kg	swl tested
10	8	19	16	32	7.000	1.000
12,7	10	25	20	40	10.000	2.000
16	12,7	32	25	50	15.000	3.000
19	16	37	32	64	25.000	5.000
22,2	19	44	38	76	35.000	7.000
25,4	22,2	51	44	88	45.000	9.000
28,6	25,4	57	51	102	55.000	11.000
31,8	28,6	64	57	114	65.000	13.000
34,9	31,8	70	64	128	75.000	15.000
38	34,9	76	70	140	90.000	18.000

STAINLESS STEEL SHACKLES, BOWED

Details

STAINLESS STEEL SHACKLES, BOWED

a mm	b mm	c mm	d mm	weight per piece in kg	swl 6:1 ton
38	25	58	84	2,4	6
50	33	75	114	3,8	8
50	37	84	119	5,5	10
64	44	101	141	9,5	15
79	51	131	180	16	25

a mm	b mm	c mm	d mm	weight per piece in kg	swl 6:1 ton
38	25	58	84	2,4	6
50	33	75	114	3,8	8
50	37	84	119	5,5	10
64	44	101	141	9,5	15
79	51	131	180	16	25
